DESCRIPTION
The iPCM12 Installed Personnel Contamination Monitor offers unique sculpted geometry and improved sensitivity due to smaller detector size.
- The detection area is an industry-leading 17,000 cm² .
- Three optional detectors can be mounted to monitor the shoulder, side of the foot and the top of the head.
- Sum zones may be applied across all detectors, providing at least 250 zones per measurement and counting channel.
- Multilanguage voice prompts provide verbal instructions during monitoring to ensure correct positioning and actions required following an alarm.
- All background, measurement, source checking, event log, voltage scanning is stored to an SQL database within the monitor, providing both local and remote access.
- Alarms may be set on single detectors or sum zones, leading to very low detection limits for distributed contamination.
- Each measurement result may be stored against a personnel identifier.
- Rapid recovery from background changes with a dynamic background counting time.
- Large touchscreen LCD.
- USB security dongle allows supervisors access to diagnostic modes to further investigate the results; features three security levels.
- QuickScan algorithm allows for faster beta and gamma contamination monitoring without compromising the statistical probabilities of detection or false alarm.
- Changing background indication signal highlights significant changes in background radiation
- Changing conditions alarm indicates if there is a significant change in the count rate during the monitoring period, invalidating the measurement.
- Calibration Integrity checking.
- Windows™ operating system and Series 12 Software based upon that in SAM12 and PM12.
- USB and Ethernet connectivity.
- A gamma option provides up to nine scintillation detectors, monitoring the body, head, and feet; with this option, users can set both gross and 60CO alarms.
- Optional ingress/egress doors are also available.
